ideaForge SWITCH UAV
Model SWITCH
Hybrid VTOL fixed-wing UAV for high-altitude ISR, with 2+ hours endurance, 15 km link and 25x zoom or 640x480 thermal payloads.
- Airframe type
- fixed wing and VTOL hybrid UAV
- Max take-off weight
- < 7 Kg (UAV Weight with battery and max. payload)
- Flight time
- >120 minutes with either payload (upto 1000m AMSL Takeoff)
- Operating range
- 15 km (un-obstructed & interference free)
- Optical zoom
- Daylight HD (1280X720) with 25x optical zoom
- Thermal resolution
- Thermal 640X480 video payload
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Vendor replies
Where to buy
Not sold online yet. Ask IdeaForge for a quote, delivery and dealers near you with “Get a quote” above.
About this product
SWITCH is ideaForge's first-generation hybrid fixed-wing VTOL UAV for long-range, high-altitude surveillance. Its specification table lists a weight under 7 kg, size under 2.6 x 1.8 m, more than 120 minutes of endurance, a 15 km live-transmission range on 2.4 GHz with AES-128 encryption, cruise around 13 m/s, and launch altitudes up to 4000 m AMSL. Payloads are a 25x optical-zoom HD daylight camera or a 640x480 thermal camera. The maker states testing to JSS 55555 and MIL-STD-461E. It holds DGCA type certificate T08250000001/00; on its type-certified page ideaForge lists 90 minutes maximum endurance and 2 km maximum range for the certified configuration. SWITCH V2 has since been launched.
Specifications
18 of 18 published by the vendor. “Ask the vendor” means the brochure does not say.
General
- Airframe type
- fixed wing and VTOL hybrid UAV
- Max take-off weight (MTOW)
- < 7 Kg (UAV Weight with battery and max. payload)
- Dimensions (L × W × H)
- <2.6m x 1.8m
Datalink
- Datalink frequency bands
- 2.4GHz
- Encrypted datalink
- 128-bit AES encryption
Compliance
- DGCA type certified
- TC Issued on 25th August 2025; model 'SWITCH'
- DGCA type certificate number
- TC No: T08250000001/00
Flight
- Flight time (endurance)
- >120 minutes with either payload (upto 1000m AMSL Takeoff)
- Operating range
- 15 km (un-obstructed & interference free)
- Maximum speed
- 25 m/s Maximum Speed
- Cruise speed
- ~13 m/s @ MSL
- Wind resistance
- Upto 20kmph(Take-off/Landing); Upto 40kmph(In-flight)
- Max operating altitude (AGL)
- 1000m AGL
Power
- Power source
- Battery Powered Electric Propulsion
Environment
- Operating temperature
- -15°C to +55°C
Operations
- Deployment / setup time
- < 15 minutes Deployment Time
Camera
- Optical zoom
- Daylight HD (1280X720) with 25x optical zoom
- Thermal resolution
- Thermal 640X480 video payload
Certifications
- DGCA Type Certificate (UAS) (DGCA / QCI)No. T08250000001/00
More details
- Made in
- India
ideaForge SWITCH UAV
