1 / 2Indrones Vector VTOL Fixed-Wing ISR UAV
Model Vector VTOL
VTOL fixed-wing UAV of about 12 kg for long-endurance surveillance and mapping, takes off from a 25 x 25 m space, 2 kg payload.
Sold byINDRONES SOLUTIONS PRIVATE LIMITED Vashi- Airframe type
- VTOL launch method, fixed-wing
- Max take-off weight
- 12 kg
- Flight time
- 120 Minutes
- Operating range
- Flight Range 5 Km
- Payload capacity
- 2kg payload capacity
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Vendor replies
Where to buy
Not sold online yet. Ask INDRONES SOLUTIONS PRIVATE LIMITED for a quote, delivery and dealers near you with “Get a quote” above.
About this product
Vector VTOL is the vertical take-off version of Indrones' Vector fixed-wing platform, intended for surveillance, patrol and mapping where no runway or launcher is available; Indrones states it can operate from a 25 x 25 m area. The datasheet lists a maximum take-off weight of 12 kg, a 20,000 mAh battery, 120 minutes flight time, 24 m/s cruise speed and wind resistance up to 14 m/s. It carries up to 2 kg and takes the same interchangeable payload family as Vector, including RGB survey, 10x zoom, radiometric thermal, multispectral, oblique and LiDAR sensors. No DGCA type certificate was found for this model.
Specifications
12 of 12 published by the vendor. “Ask the vendor” means the brochure does not say.
General
- Airframe type
- VTOL launch method, fixed-wing
- Max take-off weight (MTOW)
- 12 kg
- Dimensions (L × W × H)
- 2870x1640x635 (mm)
Flight
- Flight time (endurance)
- 120 Minutes
- Operating range
- Flight Range 5 Km
- Cruise speed
- 24 m/s
- Wind resistance
- Up to 14 m/s
- Service ceiling (AMSL)
- 4500m AMSL ceiling altitude
- Max operating altitude (AGL)
- 400 ft AGL
Payload
- Payload capacity
- 2kg payload capacity
Power
- Power source
- Battery 20000 mAh
Environment
- Operating temperature
- -15°C to 45°C
INDRONES SOLUTIONS PRIVATE LIMITED
Vashi
Indrones is one of the leading drone manufacturers & a cutting-edge drone service provider in India, offering digital s…
Documents and videos
More details
- Made in
- India
