1 / 2RD-M-X6.1 KV175
Reflex Drive, offers a 175 KV Out-Runner motor, highly efficient and well-suited for agricultural and critical payload delivery applications. With a compact design, it's ideal for critical payload delivery operations, and it operates in a voltage range of 44.4V.
Sold byReflex Drive- Weight
- 355 g
- Max thrust
- 9.4 kg
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Direct reply
About this product
The RD-M-X6.1 is a compact and highly efficient 175 KV Out-Runner motor designed for agricultural drones. It can handle a peak current of 54A, delivering 2400W of power for 30 seconds. With an impressive 90.99% efficiency and a maximum thrust of 9.4 KG, it's a great choice for payload delivery use. The motor is built to withstand the demands of the logistics industry, with a magnet temperature rating of 150°C, IP34 protection against dust and moisture, and a maximum operating temperature of 60°C.
Key features
- Powerful Thrust: RD-M-X6.1 With a 175 KV rating, motor provides an impressive 9.4 KG of thrust.
- Precise Control: Featuring 24/28 poles, it ensures precise control for various drone applications.
- Efficiency: Boasts a high motor efficiency of 93.57%, optimizing flight times.
- Lightweight Design: Weighing just 355g, it minimizes the overall weight of your drone.
- Peak Performance: Achieves a peak current of 54A and a peak power output of 2400W.
Specifications
6 of 7 published by the vendor. “Ask the vendor” means the brochure does not say.
General
- Weight
- 355 g
Motor
- Motor KV
- Ask the vendor
- Max thrust
- 9.4 kg
- Max power
- 2400 W
- Max (continuous) current
- 54 A
- Supported cells (S)
- 12S
- Recommended propeller
- 23*88-Folding
Documents and videos
RD-M-X6.1 KV175
Price on request
