1 / 2RD-M-X8.1 KV115
Reflex Drive, offers a 115 KV Out-Runner motor, highly efficient and well-suited for agricultural applications. With a compact design, it's ideal for agricultural drones, and it operates in a voltage range of 44.4V.
Sold byReflex Drive- Weight
- 680 g
- Max thrust
- 16.6 kg
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Direct reply
About this product
The RD-M-X8.1 is a compact and highly efficient 115 KV Out-Runner motor designed for agricultural drones. It can handle a peak current of 90A, delivering 3996W of power for 30 seconds. With an impressive 90.99% efficiency and a maximum thrust of 16.64 KG, it's a great choice for agricultural use. The motor is built to withstand the demands of the field, with a magnet temperature rating of 150°C, IP34 protection against dust and moisture, and a maximum operating temperature of 60°C.
Key features
- Powerful Thrust: RD-M-X8.1 With a 115 KV rating, motor provides an impressive 16.64 KG of thrust.
- Precise Control: Featuring 36/42 poles, it ensures precise control for various drone application
- Efficiency: Boasts a high motor efficiency of 90.99%, optimizing flight times.
- Lightweight Design: Weighing just 680g, it minimizes the overall weight of your drone.
- Peak Performance: Achieves a peak current of 90A and a peak power output of 3996W.
Specifications
6 of 7 published by the vendor. “Ask the vendor” means the brochure does not say.
General
- Weight
- 680 g
Motor
- Motor KV
- Ask the vendor
- Max thrust
- 16.6 kg
- Max power
- 3996 W
- Max (continuous) current
- 90 A
- Supported cells (S)
- 12S
- Recommended propeller
- 30*90-Folding
