1 / 2Bharath Components Dual-Antenna GNSS Module (DroneCAN)
Model Bharath GNSS
Dual-antenna drone GNSS (30 cm baseline) for GPS, GLONASS, Galileo, BeiDou and SBAS, DroneCAN at 1 Mbps, 2.5 W, -40 to +85 C.
- GNSS constellations
- Supporting Constellations GPS, GLONASS, GALILEO, BeiDou, SBAS
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Vendor replies
Where to buy
Not sold online yet. Ask IoTechWorld Avigation for a quote, delivery and dealers near you with “Get a quote” above.
About this product
Bharath GNSS is a satellite positioning module from Bharath Components, IoTechWorld's component subsidiary. It tracks GPS, GLONASS, Galileo, BeiDou and SBAS and uses a master and slave antenna pair on a 30 cm baseline, a layout normally used to derive heading as well as position. It connects to the flight controller over DroneCAN at 1 Mbps, runs on 4.7-5.2 V at 2.5 W, measures 67 x 84 x 18 mm and is rated from -40 to +85 C. The page does not state RTK capability, update rate or positioning accuracy figures.
Specifications
4 of 4 published by the vendor. “Ask the vendor” means the brochure does not say.
Environment
- Operating temperature
- -40℃ – +85℃
General
- Dimensions (L × W × H)
- 67 × 84 × 18 mm
GNSS
- GNSS constellations
- Supporting Constellations GPS, GLONASS, GALILEO, BeiDou, SBAS
- Interfaces & ports
- Data Protocol Dronecan – 1 Mbps; Connectors Master Antenna, Slave Antenna, CAN
More details
- Made in
- India
