JASPER Indoor Autonomous Inspection Drone
Model JASPER
Caged indoor quadcopter with LiDAR SLAM for GPS-denied flight, 40 TOPS onboard AI, 4K and 640x512 thermal cameras, 35 min flight.
Sold byVecros Technologies Bengaluru- Airframe type
- Carbon-fiber reinforced unibody with integrated propeller guards (four-rotor caged frame in images)
- Flight time
- Max flight time 35 MINS
- Operating range
- Max range 5 KM (FCC)
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Vendor replies
Where to buy
Not sold online yet. Ask Vecros Technologies for a quote, delivery and dealers near you with “Get a quote” above.
About this product
JASPER is Vecros's compact autonomous drone for warehouses, plants and other indoor sites where GPS is unavailable. It navigates with onboard SLAM using 360-degree LiDAR (30 m range) and ultrasonic sensors, holding position to about 5 cm and flying repeatable 3D patrol routes with one-click launch. A carbon-fibre frame with integrated propeller guards measures 245 x 245 x 85 mm and weighs 890 g without battery. Sensing includes a 12 MP 4K/60 fps camera with LED lighting and a 640 x 512 thermal camera, processed on an NVIDIA Jetson Orin with 40 TOPS, 8 GB RAM and a 512 GB SSD. Flight time is up to 35 minutes; the 2.4/5.8 GHz link is AES-256 encrypted and carries 1080p 30 fps video. Uses include stock counts, thermal checks of machinery and tank inspection.
Specifications
15 of 16 published by the vendor. “Ask the vendor” means the brochure does not say.
General
- Airframe type
- Carbon-fiber reinforced unibody with integrated propeller guards (four-rotor caged frame in images)
- Max take-off weight (MTOW)
- Ask the vendor
- Number of rotors
- 4 propellers visible in hero and exploded-view images
- Empty weight (without battery/payload)
- Weight (w/o battery) 890 G
- Dimensions (L × W × H)
- Dimensions 245 × 245 × 85 MM
Datalink
- Datalink frequency bands
- Radio frequency 2.4 / 5.8 GHZ
- Encrypted datalink
- Encryption AES-256; Encrypted Control Link
Flight
- Flight time (endurance)
- Max flight time 35 MINS
- Operating range
- Max range 5 KM (FCC)
- Maximum speed
- Max speed 12 M/S (MANUAL)
- Wind resistance
- Wind resistance 10 M/S
Navigation
- Navigation & positioning
- Navigation: SLAM; GPS dependency: ZERO
- Hover accuracy (horizontal)
- Precision XYZ ±5 CM
- Obstacle avoidance
- Obstacle avoidance OMNIDIRECTIONAL; 360° LiDAR coverage combined with ultrasonic proximity sensors
Power
- Power source
- Smart BMS with individual cell monitoring
Payload
- Included payload / camera
- Main camera 12MP 4K @ 60FPS; Thermal resolution 640 × 512 PX; LiDAR range 30 M
More details
- Made in
- India
