1 / 3JETCORE Carrier Board for NVIDIA Jetson
Model JETCORE
86 x 67 mm, 40 g carrier board for Jetson Orin Nano/NX, Xavier NX and TX2 NX with 7 USB 3.0, GbE, dual CSI, PCIe, CAN and onboard IMU.
Sold byVecros Technologies Bengaluru- Weight
- WEIGHT 40 g
- Processor
- JETSON SUPPORT Orin Nano / NX · Xavier NX · TX2 NX; Jetson module not included
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Vendor replies
Where to buy
Not sold online yet. Ask Vecros Technologies for a quote, delivery and dealers near you with “Get a quote” above.
About this product
JETCORE is a compact carrier board from Vecros that turns an NVIDIA Jetson module into an edge computer for drones and robots. It accepts Jetson Orin Nano, Orin NX, Xavier NX and TX2 NX modules (sold separately) and provides up to seven USB 3.0 ports, HDMI, Gigabit Ethernet, two MIPI CSI camera inputs, PCIe expansion for SSDs or accelerators, and I2C, CAN, PWM and GPIO for sensors and actuators. A BMI088 IMU is fitted on the board. It measures 86 x 67 x 18 mm, weighs 40 g, runs from 12 to 18 V DC through an XT30 connector and is rated for -40 to +85 C. The box includes power and flat cables; a bundle with an NVIDIA Jetson Nano developer kit is also sold.
Specifications
6 of 6 published by the vendor. “Ask the vendor” means the brochure does not say.
Environment
- Operating temperature
- OPERATING TEMP –40°C to +85°C
General
- Weight
- WEIGHT 40 g
- Dimensions (L × W × H)
- DIMENSIONS 86 × 67 × 18 mm
- Compatible with
- POWER INPUT 12V – 18V DC; IMU BMI088
Hardware
- Processor
- JETSON SUPPORT Orin Nano / NX · Xavier NX · TX2 NX; Jetson module not included
- Interfaces & ports
- Up to 7× USB 3.0; 1× Gigabit Ethernet; 2× CSI MIPI; HDMI; PCIe · I2C · CAN · PWM · GPIO
More details
- Made in
- India
