1 / 2Surveyaan V1RC Plus Survey Drone
Model V1RC PLUS
Carbon-frame survey quadcopter with 40-45 min endurance, 2.5 km range and swappable non-PPK, PPK and video payloads for mapping up to 1 sq km per flight.
Sold bySurveyaan Bengaluru- Airframe type
- Drone Type Quad-Rotor
- Max take-off weight
- Weight with Payload 2.650 Kg
- Flight time
- Endurance 40-45 Min
- Operating range
- 2.5 Km Range
- Mapping coverage per flight
- Survey upto 1 Sq km in a single flight
- RTK / PPK
- PPK, Non-PPK & Surveillance Payloads
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Vendor replies
Where to buy
Not sold online yet. Ask Surveyaan for a quote, delivery and dealers near you with “Get a quote” above.
About this product
The Surveyaan V1RC Plus is a quadcopter for larger mapping jobs, built by Nibrus Technologies in Bengaluru on a carbon-fibre frame that the maker rates for 3,000 mapping cycles. It flies for 40-45 minutes with a 2.5 km range and a 120 m ceiling, weighs 2.65 kg with payload and can cover up to 1 sq km in a single flight. Three payloads are offered: a 23 MP camera for standard photogrammetry, a 20 MP APS-C camera with an L1/L2 GNSS receiver for PPK, and a stabilised 2K video camera with 720p live feed for site monitoring. The maker quotes under 5 cm horizontal and 10 cm vertical accuracy with ground control points. It has dual processors and several return-to-home failsafes, and the kit weighs under 5 kg. The maker calls it DGCA compliant but publishes no type certificate.
Specifications
13 of 13 published by the vendor. “Ask the vendor” means the brochure does not say.
General
- Airframe type
- Drone Type Quad-Rotor
- Max take-off weight (MTOW)
- Weight with Payload 2.650 Kg
- DGCA weight class
- Small Category 2.65 Kg Max with Payload
- Number of rotors
- Drone Type Quad-Rotor
Flight
- Flight time (endurance)
- Endurance 40-45 Min
- Operating range
- 2.5 Km Range
- Wind resistance
- Max Wind 25 kmph
- Max operating altitude (AGL)
- Max Altitude 120 m
Payload
- Included payload / camera
- Non-PPK Payload is a 23 MP camera with a 1/2.3-inch sensor ... PPK RGB Payload is a 20 MP APS-C sensor camera with L1/L2 GNSS ... Surveillance Payload supports 2K video recording, 3-axis stabilisation, and live 720p transmission
Operations
- Deployment / setup time
- Ready in 5 Minutes
Mapping
- Mapping coverage per flight
- Survey upto 1 Sq km in a single flight
- RTK / PPK
- PPK, Non-PPK & Surveillance Payloads
- Positioning accuracy (horizontal)
- Accuracy & RMSE < 5 cm (X,Y) | < 10 cm (Z)
Surveyaan
Bengaluru
Surveyaan (Indian drone manufacturing company), by Nibrus Technologies Pvt Ltd, manufactures affordable typecertified d…
More details
- Made in
- India
