1 / 2Mechtex DM3115 900KV Drone Motor
Model DM3115
Mechtex DM3115 brushless motor, 900-1050 KV, for 4-6S FPV and performance multirotors, 5.1 kgf max thrust, 126 g.
Sold byMechtex Navi Mumbai- Weight
- Weight 126 g
- Motor KV
- KV 900 - 1050 KV
- Max thrust
- Max Thrust 5.1 Kg
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Vendor replies
Where to buy
Not sold online yet. Ask Mechtex for a quote, delivery and dealers near you with “Get a quote” above.
About this product
The Mechtex DM3115 is a taller 31x15 class brushless motor for 4S to 6S FPV freestyle, racing and other performance multirotors. Mechtex quotes 5.1 kg of maximum thrust from a 126 g motor, a 12N14P stator and a 37 mm diameter by 32 mm height. The catalogue card lists it at 900 KV and the page gives a 900 to 1050 KV range, which suggests more than one winding is available on request. Current, power and prop size are not published for this model.
Specifications
5 of 5 published by the vendor. “Ask the vendor” means the brochure does not say.
General
- Weight
- Weight 126 g
- Dimensions (L × W × H)
- Dimension Ø 37 * 32 mm
Motor
- Motor KV
- KV 900 - 1050 KV
- Max thrust
- Max Thrust 5.1 Kg
- Supported cells (S)
- Rated Voltage 4-6 S
Mechtex
Navi Mumbai
MECHTEX is a leading global manufacturer of a wide range of industrial motors and motion control products including syn…
More details
- Made in
- India
