1 / 3Flameback 2206 KV1600 BLDC Motor
Model FBT-BLDC-2206
Flameback 2206 KV1600 brushless motor for 3S freestyle FPV and mid-size quads, about 554 gf max thrust on 7 inch props.
Sold byFlameback Tech Baddi- Motor KV
- 2206 KV 1600
- Max thrust
- Max Thrust: 553.9 gF
- Stator size
- 22×6 stator
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Vendor replies
Where to buy
Not sold online yet. Ask Flameback Tech for a quote, delivery and dealers near you with “Get a quote” above.
About this product
The Flameback 2206 KV1600 is a 22x6 mm stator brushless motor aimed at 3S freestyle and racing quads and stable camera platforms that swing larger 7 inch props. Flameback quotes 553.9 gf of maximum thrust and about 245 gf at half throttle, with a 20 A current limit and 200 W tested peak power. It uses a 12N14P winding and a finned aluminium bell. The maker recommends its 25A ESC and tested it with a 7x4 three-blade prop.
Specifications
7 of 7 published by the vendor. “Ask the vendor” means the brochure does not say.
Motor
- Motor KV
- 2206 KV 1600
- Max thrust
- Max Thrust: 553.9 gF
- Stator size
- 22×6 stator
- Max power
- Max Power (Tested) 200 W
- Max (continuous) current
- Max Current: 20A
- Supported cells (S)
- Operating Voltage: 3S
- Recommended propeller
- Recommended Props: 7 inches
Flameback Tech
Baddi
Flameback Tech delivers UAV components including ESCs, BLDC motors, propellers & controllers.
Documents and videos
More details
- Made in
- India
