1 / 3Flameback 8320 KV120 BLDC Motor
Model FBT-BLDC-8320-120
Flameback 8320 KV120 brushless motor for 12S heavy-lift and cargo drones, about 16.4 kgf max thrust on 30 inch props, 660 g.
Sold byFlameback Tech Baddi- Weight
- Weight incl. cables 660 g
- Motor KV
- 8320 KV 120
- Max thrust
- Max Thrust: 16377 gF
- Stator size
- 8320
Price
Price on request
Ask for a quote for your quantity and delivery location.
- Free
- No account
- Vendor replies
Where to buy
Not sold online yet. Ask Flameback Tech for a quote, delivery and dealers near you with “Get a quote” above.
About this product
The Flameback 8320 KV120 is the larger sibling of the 6220, an 83x20 mm stator motor for 12S heavy-lift agricultural, cargo and large inspection drones. Flameback quotes 16377 gf of maximum thrust and about 5432 gf at half throttle on a 30 inch prop, an 80 A current limit and 3000 W tested peak power. It weighs 660 g with cables and uses a 36N42P winding. The maker recommends its 80A ESC and a 3011 prop.
Specifications
8 of 8 published by the vendor. “Ask the vendor” means the brochure does not say.
General
- Weight
- Weight incl. cables 660 g
Motor
- Motor KV
- 8320 KV 120
- Max thrust
- Max Thrust: 16377 gF
- Stator size
- 8320
- Max power
- Max Power (Tested) 3000 W
- Max (continuous) current
- Max Current: 80A
- Supported cells (S)
- Operating Voltage: 12S
- Recommended propeller
- Recommended Props: 30 inch
Flameback Tech
Baddi
Flameback Tech delivers UAV components including ESCs, BLDC motors, propellers & controllers.
Documents and videos
More details
- Made in
- India
